Product Summary
The S5A3159DCKR is a single-pole double throw (SPDT) analog switch that is designed to operate from 1.65-V to 5.5-V. The device offers a low ON-state resistance and an excellent ON-resistance, matching with the break-before-make feature to prevent signal distortion during the transferring of a signal from one channel to another. The S5A3159DCKR has an excellent total harmonic distortion (THD) performance and consumes very low power. These features make this device suitable for portable audio applications. The applications of the S5A3159DCKR are Cell Phones, PDAs, Portable Instrumentation.
Parametrics
S5A3159DCKR absolute maximum ratings: (1)Supply voltage range:-0.5 to 6.5V; (2)Analog voltage range:-0.5 to V+ + 0.5V; (3)Analog port diode current:±50mA; (4)ON-state switch current:±200mA; (5)ON-state peak switch current:±400mA; (6)Digital input voltage range:-0.5 to 6.5V; (7)Digital input clamp current:-50mA; (8)Continuous current through V+ or GND:±100mA; (9)Package thermal impedance:165℃; (10)Storage temperature range:-65℃ to 150℃.
Features
S5A3159DCKR features: (1)Specified Break-Before-Make Switching; (2)Low ON-State Resistance (1Ω); (3)Control Inputs Are 5-V Tolerant; (4)Low Charge Injection; (5)Excellent ON-Resistance Matching; (6)Low Total Harmonic Distortion; (7)1.65-V to 5.5-V Single-Supply Operation; (8)Latch-Up Performance Exceeds 100 mA Per JESD 78, Class II; (9)ESD Performance Tested Per JESD 22: 2000-V Human-Body Mode(A114-B, Class II), 1000-V Charged-Device Model (C101).
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 TS5A3159DCKR |
Texas Instruments |
Analog Switch ICs 1-Ohm SPDT Analog Switch |
Data Sheet |
|
|
||||||||||||
|
TS5A3159DCKRE4 |
Texas Instruments |
Analog Switch ICs 1-Ohm SPDT Analog Switch |
Data Sheet |
|
|
||||||||||||
|
TS5A3159DCKRG4 |
Texas Instruments |
Analog Switch ICs 1O SPDT Ana Sw |
Data Sheet |
|
|
||||||||||||
