Product Summary
The 3SK299 is a MES field EFFECT transistor.
Parametrics
3SK299 absolute maximum ratings: (1)Drain to Source Voltage VDSX: 13 V; (2)Gate1 to Source Voltage VG1S: –4.5 V; (3)Gate2 to Source Voltage VG2S: –4.5 V; (4)Drain Current ID: 40 mA; (5)Total Power Dissipation PT: 120 mW; (6)Channel Temperature Tch: 125 ℃; (7)Storage Temperature Tstg: –55 to +125 ℃.
Features
3SK299 features: (1)Suitable for use as RF amplifier in UHF TV tuner; (2)Low Crss : 0.02 pF TYP; (3)High GPS : 20 dB TYP; (4)Low NF : 1.1 dB TYP; (5)4 pin small mini mold package.
Diagrams
