Product Summary

The BC847B is an NPN general purpose transistor. It is in a SOT23 plastic package. The device is designed for general purpose switching and amplification.

Parametrics

BC847B absolute maximum ratings: (1)VCBO collector-base voltage: 50 V; (2)VCEO collector-emitter voltage: 45 V; (3)VEBO emitter-base voltage: 6 V; (4)IC collector current (DC): 100 mA; (5)ICM peak collector current: 200 mA; (6)IBM peak base current: 200 mA; (7)Ptot total power dissipation: 250 mW; (8)Tstg storage temperature: -65 to +150 ℃; (9)Tj junction temperature: 150 ℃; (10)Tamb operating ambient temperature: -65 to +150 ℃.

Features

BC847B features: (1)Low current (max. 100 mA); (2)Low voltage (max. 65 V).

Diagrams

BC847B diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
BC847B,215
BC847B,215

NXP Semiconductors

Transistors Bipolar (BJT) NPN/PNP 45V 100MA

Data Sheet

0-1: $0.03
1-25: $0.01
25-100: $0.01
100-500: $0.01
BC847B,235
BC847B,235

NXP Semiconductors

Transistors Bipolar (BJT) TRANS GP TAPE-13

Data Sheet

0-1: $0.03
1-25: $0.03
25-100: $0.03
100-250: $0.02
BC847B_L99Z
BC847B_L99Z

Fairchild Semiconductor

Transistors Bipolar (BJT) SOT-23 NPN GP AMP

Data Sheet

Negotiable
BC847B-7
BC847B-7

Diodes Inc.

Transistors Bipolar (BJT) NPN BIPOLAR

Data Sheet

Negotiable
BC847B-7-F
BC847B-7-F

Diodes Inc.

Transistors Bipolar (BJT) NPN BIPOLAR

Data Sheet

0-1: $0.11
1-10: $0.07
10-100: $0.05
100-250: $0.04
BC847BDW1T3G
BC847BDW1T3G

ON Semiconductor

Transistors Bipolar (BJT) 100mA 50V Dual NPN

Data Sheet

0-1: $0.14
1-25: $0.10
25-100: $0.05
100-500: $0.04
BC847BLD-7
BC847BLD-7

Diodes Inc.

Transistors Bipolar (BJT) NPN BIPOLAR

Data Sheet

0-1: $0.15
1-10: $0.14
10-100: $0.08
100-250: $0.05
BC847BPDW1T3G
BC847BPDW1T3G

ON Semiconductor

Transistors Bipolar (BJT) SS SC88 GP XSTR DUAL 45V

Data Sheet

0-1: $0.03
1-25: $0.02
25-100: $0.02
100-250: $0.02
