Product Summary
The MCD95-16i01B is a thyistor/diode module. The applications of it are DC motor control, Softstart AC motor controller, Light, heat and temperature control.
Parametrics
MCD95-16i01B absolute maximum ratings: (1)ITRMS,IFRMS:180A; (2)ITAVM,IFAVM:116A; (3)PGM:10W or 5W; (4)PGAV:0.5W; (5)VRGM:10V; (6)TVJ:-40℃ to +125℃; (7)TVJM:+125℃; (8)Tstg:-40℃ to +125℃; (9)Visol:3000V or 3600V; (10)Weight:90g.
Features
MCD95-16i01B features: (1)International standard package,JEDEC TO-240 AA; (2)Direct copper bonded Al2O3 -ceramic base plate; (3)Planar passivated chips; (4)Isolation voltage 3600 V; (5)UL registered, E 72873; (6)Gate-cathode twin pins for version 1.
Diagrams
 |
