Product Summary

The NZT751 is a PNP Current Driver Transistor.

Parametrics

NZT751 absolute maximum ratings: (1)VCEO Collector-Emitter Voltage: 60 V; (2)VCBO Collector-Base Voltage: 80 V; (3)VEBO Emitter-Base Voltage: 5.0 V; (4)IC Collector Current - Continuous: 4.0 A; (5)TJ, Tstg Operating and Storage Junction Temperature Range: -55 to +150 ℃.

Features

NZT751 features: (1)PD Total Device Dissipation: 1.2W; (2)Derate above 25℃: 9.7mW/℃; (3)RqJA Thermal Resistance, Junction to Ambient: 103 ℃/W.

Diagrams

NZT751 view

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
NZT751
NZT751

Fairchild Semiconductor

Transistors Bipolar (BJT) PNP Transistor Current Driver

Data Sheet

0-1: $0.35
1-25: $0.30
25-100: $0.26
100-250: $0.21
NZT751_Q
NZT751_Q

Fairchild Semiconductor

Transistors Bipolar (BJT) PNP Transistor Current Driver

Data Sheet

Negotiable
