Product Summary
The PKC2132PI is a DC/DC power module. It is especially designed for decen-tralized 24 and 28 Vdc systems with distributed on-board DC/DC converters. Extreme temperature conditions can be met since the PKC2132PI can operate with full output power in ambient temperatures from –45℃ to +85℃, or up to +115℃ case temperature also making the products ideal for applications within not temperature controlled environments. The PKC2132PI is manufactured using highly automated manufacturing lines with a world-class quality commitment and a five-year warranty.
Parametrics
PKC2132PI absolute maximum ratings: (1)Case temperature:-45℃ to +115℃; (2)Transient input energy:0.6 Ws; (3)Storage temperature:-55℃ to +125℃; (4)Input voltage:-0.5 to 36 Vdc; (5)Remote control voltage pin 1:0 to 5 Vdc; (6)Input to output isolation:500 Vdc.
Features
PKC2132PI features: (1)Regulated single, dual and triple outputs; (2)Low profile 10.7 mm (0.42 in.), allows 0.8” board pitch - 0.6 in. if recessed in the printed board; (3)Proven MTBF >2,000,000 hours at +75℃ case temperature and a rugged mechanical construction; (4)Efficiency 85% typ, at full load. No extra heatsink up to +85℃ ambient. Max.+115℃ case; (5)Low EMI in conformance with class A in EN 55022 and FCC part 15J.
Diagrams
