Product Summary

The TZ500N16KOF single scr module comes in industry standard packages. The modules can be used individually or as power control building blocks. The high thermal efficiency of TZ500N16KOF assures long life and reliable performance. Two different package sizes allow for a maximum output current of 800 amps for standard scr and 335 amps for fast switching versions. Blocking voltages are available as high as 3600 volts for standard scr and 1200 volts for fast switching modules. Turn off times are as low as as 25 microseconds.

Parametrics

TZ500N16KOF absolute maximum ratings: (1)It (avg): 500 Amps; (2)It (RMS): 1,050 Amps; (3)Vrrm: 1,600 Volts; (4)Tq: 250 MicroSeconds; (5)Igt: 250 MilliAmps; (6)di/dt (Amps/MicroSec.): 200; (7)dv/dt (Volts/MicroSec.): 1,000.

Features

TZ500N16KOF features: (1)Single SCR Module; (2)Blocking Voltages to 3600 Volts; (3)High Thermal Efficiency; (4)2500 Vrms Isolation; (5)Industry Standard Packages.

Diagrams

TZ500N16KOF circuit diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
TZ500N16KOF
TZ500N16KOF

Infineon Technologies

Discrete Semiconductor Modules 1600V 1050A SINGLE

Data Sheet

0-1: $136.07
1-5: $122.47
