MD2202-D16-P

Disk OnChip 2000, DIP, Low power consumption, 16MB to 576MB, Boot OS capability, 8KB sized memory window

Rated 5 Rating 5 | reviews | Write a review

Price:: US $12.00~13.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $12.00~13.00

PartNumber:: MD2202-D16-P

Brand:: M Systems International, Inc. - MSYSTEMS | Pack: DIP | D/C: 07+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. lily zhong's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-09-20

From Other Seller

Part Number:MD2202-D16-P
US $12.00 - 13.00
EKY-160ELL121MF11D

US $0.10 - 1.00 / Piece
(0) Remove
ECA1HHG4R7

US $10.00 - 10.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The MD2202-D16-P product line is the second-generation of M-Systems’ DiskOnChip series of products. The 2000 series provides a small, single-chip, solid-state flash disk in a standard 32-pin DIP package. Combining a disk controller with flash memory on a single chip, MD2202-D16-P is the solution where minimal weight, space, and power consumption are essential. In consequence, the 2000 series finds use today in a wide range of products, such as information appliances, set-top boxes, thin clients, thin servers, network computers, and embedded, portable computers. By placing MD2202-D16-P in a standard socket, physical space requirements are reduced. Unlike standard IDE drives, no cables or extra space are required. MD2202-D16-P has no moving parts, resulting in significantly decreased power consumption and increased reliability. It is easy to use and reduces integration overhead. MD2202-D16-P is therefore a very attractive alternative to conventional hard and floppy disk drives.

Parametrics

MD2202-D16-P absolute maximum ratings: (1)DC supply voltage VCCS: -0.5 to 4.6 or -0.3 to 6.0 V; (2)Input pin voltage VIN: -0.5 to VCC + 0.3 or -0.3 to VCC + 0.3 V; (3)Input pin current IIN: Not Specified -10 to 10 mA.

Features

MD2202-D16-P features: (1)Single-chip plug-n-play flash disk; (2)Low power, single 3.3V or 5V power supply; (3)16MB to 576MB capacity (1GB in 2002); (4)Pinout and structure compatible with DiskOnChip Millennium DIP 8MB; (5)Simple, easy-to-integrate interface; (6)32-pin DIP, JEDEC standard, EEPROM-compatible pinout; (7)8KB sized memory window; (8)Boot OS capability; (9)Embedded TrueFFS. software provides: Full hard disk read/write emulation; Third-generation wear leveling; Automatic block management; (10)Operates with DiskOnChip SDK in OS-less environments, ANSI-C source code kit; (11)Error Detection and Correction (EDC/ECC) for higher data reliability; (12)Low power consumption-Static Operation.
