Product Summary

The MURS120T3G is a Surface Mount Ultrafast Power Rectifier, ideally suited for high voltage, high frequency rectification, or as free wheeling and protection diodes in surface mount applications where compact size and weight are critical to the system.

Parametrics

MURS120T3G absolute maximum ratings: (1)Peak Repetitive Reverse Voltage, VRRM: 200 V; (2)Average Rectified Forward Current IF(AV): 1.0A @ TL = 155℃; (3)Non.Repetitive Peak Surge Current (Surge applied at rated load conditions halfwave, single phase, 60 Hz), IFSM: 40 to 35 A; (4)Operating Junction Temperature TJ: -65 to +175 ℃.

Features

MURS120T3G features: (1)Pb-Free Packages are Available; (2)Small Compact Surface Mountable Package with J-Bend Leads; (3)Rectangular Package for Automated Handling; (4)High Temperature Glass Passivated Junction; (5)Low Forward Voltage Drop (0.71 to 1.05 Volts Max @ 1.0 A,; (6)TJ = 150℃).

Diagrams

MURS120T3G MARKING DIAGRAM

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
MURS120T3G
MURS120T3G

ON Semiconductor

Rectifiers 200V 1A Ultrafast

Data Sheet

0-1: $0.28
1-25: $0.19
25-100: $0.15
100-500: $0.10
