Product Summary
The PS12036 is an Application Specific Intelligent Power Module. The applications of the PS12036 include Acoustic noise-less 2.2kW/400V AC Class 3 phase inverters, motor control applications, and motors with built-in small size inverter package.
Parametrics
PS12036 absolute maximum ratings: (1)Supply voltage: 900 V; (2)Supply voltage (surge): 1000 V; (3)Each IGBT collector-emitter static voltage: 1200 V; (4)Each IGBT collector-emitter switching voltage: 1200 V; (5)Each IGBT collector current: ±15 (±30) A.
Features
PS12036 features: (1)Converter bridge for 3 phase AC-to-DC power conversion; (2)3 phase IGBT inverter bridge configured by the latest 3rd. generation IGBT and diode technology.
Diagrams
Image | Part No | Mfg | Description | Pricing (USD) |
Quantity | |||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
PS12036 |
MOD IPM 3PHASE IGBT 1200V 15A |
Data Sheet |
Negotiable |
|
||||||||||||||
