Product Summary

The IRF7380TRPBF is a HEXFET Power MOSFET. The application of it is High frequency DC-DC converters.

Parametrics

IRF7380TRPBF absolute maximum ratings: (1)Drain-to-Source Voltage: 80V; (2)Gate-to-Source Voltage:±20V; (3)Continuous Drain Current, VGS @ 10V:3.6A; (4)Continuous Drain Current, VGS @ 10V:2.9A; (5)Pulsed Drain Current:29A; (6)Maximum Power Dissipation: 2.0W; (7)Linear Derating Factor:0.02W/℃; (8)Peak Diode Recovery dv/dt:2.3V/ns; (9)Operating Junction and Storage Temperature Range:-55℃ to +150℃.

Features

IRF7380TRPBF features: (1)Low Gate to Drain Charge to Reduce Switching Losses; (2)Fully Characterized Capacitance Including Effective COSS to Simplify Design; (3)Fully Characterized Avalanche Voltage and Current.

Diagrams

IRF7380TRPBF block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
IRF7380TRPBF
IRF7380TRPBF

International Rectifier

MOSFET MOSFT DUAL NCh 80V 3.6A

Data Sheet

0-1: $0.81
1-25: $0.50
25-100: $0.34
100-250: $0.32
